"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
- Remove the 2 power screws
No. 20 Torx screwdriver
- Lift the board contact tabs
-
'RQRWWRXFKWKHFRPSRQHQWVZLWK\RXU¿QJHUV
- handle the board by its edge
LEVEL 4 - EXPERT LEVEL
- Remove the 13 measurement screws
No. 10 Torx screwdriver
DO NOT FORGET TO WEAR
AN
ANTI-STATIC BRACELET
