"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
LEVEL 3 - PELLENC AUTHORISED REPAIRER
8. Check the good holding strength of the contact in the connector. Reinstall the fuse on the battery.
200 battery connector
FOOLPROOFER OPPOSITE
BL
ACK SIGNAL WIRE
Properly position the switch, the charging connector and the power connector of the tool in their housing.
