ACU-TROL

AK110 Chemical Controller Installation and User's Guide

WARNING

Keep the Controller out of direct sunlight, inside a room if possible.

Direct sunlight on the Controller will result in inaccurate readings.

A shade screen should be used for outdoor installations.

Mounting Instructions

Select a location for mounting the Controller, meeting the following recommendations:

1. Mount at least ten (10) feet from open water.

2. Mount close enough for the supplied power cord to reach the supply voltage. The Controller will not operate

properly without a solid earth ground connection.

3. Supply power must be routed to the Controller in accordance with the applicable codes in the area; the

supplied power cord is not code in some areas.

4. The installation surface must be solid and vertical. Do not mount the Controller in a horizontal position.

WARNING

Proper and safe operation requires an earth ground connection.

5. Maintain adequate clearance for opening the front panel enclosure.

6. Theenvironmentshouldbefreeofchemicalfumesandexcessiveheat. 

 Themaximumroomtemperatureisshouldnotexceed110ºF.

7. Mount as far as possible from sources of electrical interference.

8. Install the four mounting feet as desired to the Controller back and prepare the hole to the mounting

surface as desired.

9. Hold the Controller against the mounting surface with a closed lid and mark the location of the mounting

 bracketlocatedonthetopoftheControllernexttothewall.Prepareholesasnecessaryandsecure

Controller using hardware provided.

10. Mountonaatsurface.Controllerboxwilldistortifmountedonanunevensurface.

11. Pre-install screws with ¼ left out on bottom so that the Controller can slide into them. Install the remaining

side screws and tighten.
