Pentax K100D User Manual

76700 -61/94-
◆ Gain adjustment
22-3．Preparation
1) Set the zooming position at 200mm and distance ring
set at 2m and then fix each setting with tape
2) Attach lens to the camera
3) Set the camera to the following condition
Mode dial: M
AF switch: MF
SR switch: ON
4) Attach camera to the driving stage
* Driving stage must be the horizontal position.
5) Set the camera 1.9545m from the chart and match the chart with frame
of spot measurement in the view finder
22-4. Adjustment items
SR4: Gain adjustment
The adjustment that the amount of the correction becomes the best for an actual amount of the gap
防振ユニット
補正機構
補正量
手ブレ量
Chart
Ｐ Ｃ
SR Unit
SR mechanis
m
Amount of Hand shake
Amount of correcte
d

Pentax K100D Specifications

General

Megapixel	6.1 MP
Sensor type	CCD
Interface	USB 2.0
Color depth	8 bit
Digital SLR	Yes
Video capability	No
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, selective auto focus
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 400, 800, 1600, 3200, Auto
Light exposure modes	aperture priority AE, auto, shutter priority AE
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	210000 pixels
Magnification	0.85X x
I/O ports	AV - NTSC/PAL
USB version	2.0
Product color	Black
Battery type	AA
Number of batteries supported	4
Flash modes	auto, Flash off, Red-eye reduction
Scene modes	beach, Candlelight, Children, Close-up (macro), Documents, Museum, Night, Night portrait, Portrait, Sunset, Landscape (scenery)
Photo effects	black&white, Sepia
White balance	Cloudy, daylight, flash, Fluorescent, manual, Shade, Tungsten
Camera shutter type	Electronic

Weight and Dimensions

Depth	70 mm
Width	129.5 mm
Height	92.5 mm
Weight	570 g
