Instructions for Assembly and Use – Standard Configuration
CB 160 Climbing Formwork
B1 Work on the construction site
Anchoring
Important aspects when striking
with Anchor Positioning Stud M24
– Re-straighten any bent nails.
– When retracting the formwork, nails
(5.12) must be pulled through the
plywood.
(Fig. B1.13)
Fig. B1.15
Striking
1. Loosen connections to the adjoining
elements (VKZ couplings, BFD align-
ment coupler).
2. Loosen Height Adjusting Unit CB 160 (2).
3. Tilt formwork using Adjustable Brace
CB 164-225 (3.1). (Fig. B1.15)
With this, the nails from the Anchor
Positioning Stud M24 (5.12) and box
outs are pulled out of the plywood or
at least loosened.
Important aspects when striking
with Advancing Screw M24
Loosen and remove all Advancing Bolts
M24 (5.9) from the rear side of the ply-
wood. (Fig. B1.14)
5.12
5.9
Fig. B1.13
Fig. B1.14
