CB 160 Climbing Formwork
74
Item no. Weight kg
029560 0,535 Bolt ISO 4014 M24 x 120-10.9
High-strength bolts for anchoring climbing
systems.
120
SW 36
M24
029470 0,723 Scaffold Mounting Ring M24, galv.
Anchor System M24.
For anchoring climbing systems.
73
7
3
Ø
029560 0,535
Accessories
Bolt ISO 4014 M24 x 120-10.9
710240
024360
108834
0,050
0,058
0,085
F. H. Bolts DIN 603 M8
F.H. Bolt DIN 603 M8 x 100 MU, galv.
F.H. Bolt DIN 603 M8 x 125 MU, galv.
F.H. Bolt DIN 603 M8 x 180 MU, galv.
With nut.
L B
100 80
125 113
180 28
L
B
M 8
2
1
Ø
SW 13
051650 0,060 F.H. Bolt DIN 603 M6 x 180 MU, galv.
With nut.
180
M 6
1
7
24
SW 10
051640 0,014 Lag Screw DIN 571 6 x 80, galv.
SW 10
80
