CB 160 Climbing Formwork
75
Item no. Weight kg
030840 0,516 Threaded Anchor Plate DW 15
For use with Tie Rod DW 15 or B 15. For anchoring
in concrete.
Note
Lost anchor part.
60
DW 15
Ø6
8
0
Ø
2
7
Ø
031220 1,010 Climbing Cone-2 M24/DW 15, galv.
Anchor system M24.
For anchoring climbing systems.
Note
Seperate design information on request.
50
100 25
M
2
4
D
W
1
5
7
0
SW 36
030840
030030
030740
0,516
1,440
1,550
Accessories
Threaded Anchor Plate DW 15
Tie Rod DW 15, Spec. Length
Tie Rod B 15, Spec. Length
030860 0,801 Threaded Anchor Plate DW 20
For use with Tie Rod DW 20, B 20 or Screw-On
Cone-2 M24/DW 20. For anchoring in concrete.
Note
Lost anchor part.
1
0
0
3
2
DW 20
Ø6
65
114158 1,030 Screw-On Cone-2 M24/DW 20, galv.
Anchor system M24.
For anchoring climbing systems.
Note
Separate design information on request.
2
0
D
W
65
150
7
0
2
4
M
SW 36
030860 0,801
Accessories
Threaded Anchor Plate DW 20
