CB 240 Climbing Formwork
89
Item no. Weight kg
116385 0.189 Arch. Leading Cone M24/DW 26
Leading cone for single- or double-sided architec-
tural concrete anchorings CB.
Creates a recess for Arch. Mounting Cone M24
and Concrete Cone DK 58/52.
Note
Plastic version.
80
6
2
Ø
4
5
Ø
2
6
D
W
65
115499 0.878
Accessories
Leading Cone Screw DW 26
116279 7.530 Arch. Anchor Sleeve M24-120/2
Centre piece of the double-sided architectural
concrete anchoring CB. Anchor Tie DW 15 is
passing through.
Plate size 120 mm.
Note
Order item!
Specify wall thickness D.
Seperate design information on request.
Technical Data
Min. D = 200 mm.
Max. D = 400 mm.
L = D -130 mm.
120
88
L
=
12
=
65 65
D
3
7
,5
Ø
M 24
126793
126795
3.190
3.490
Arch. Anchor Sleeves M24
Arch. Anchor Sleeve M24-150/2, D = 25
Arch. Anchor Sleeve M24-150/2, D = 30
Note
Seperate design information on request.
150
M 24
118
15
==
Ø
3
7
,5
L = 120 / 17065 65
D = 25 / 30 cm
