Adjustment
101
13.14.03 Analog Outputs
HWTerm SWTerm Function Remark
Puller X32 DC-Motor 3 Puller (option) DC Motor
Roller up X33 DC-Motor 2 Roller motor up (slave) DC Motor
Roller down X34 DC-Motor 1 Roller motor down (mas-
ter)
DC Motor
SSR_EIN X13 SSR-control Heating capacity control
unit
PWM
X24 LUFTOUT Air volume control prop. Valve
X23 RDRUCKOUT Roller pressure set value Pressure
regulating
valve
13.14.04 Analog Inputs
HWTerm SWTerm Function
AE4 X19/2 RDRUCKIN Roller pressure regulator actual value con-
trol
Pedal X14/8 Pedal Analog pedal
X35 Temp Temperature sensor
