Adjustment
93
13.12.01 Machine confi guration
With the machine confi guration function the machine control unit receives the necessary in-
formation about the attached components. If the machine components are changed, care
must be taken to make the appropriate adjustment in the machine confi guration.
● Switch on the machine and call up the input menu.
● Call up the service menu.
● Call up the menu for entering the machine confi guration.
Explanation of the functions
Input menu
This function is used to change from the initial state to the input mode.
Service menu
This function is used to call up the service menu again.
Heat sealing mode
This function is used to change to the heat sealing mode.
Feed roller diameter
This function is used to enter the diameter of the feed rollers installed.
Top/bottom/carriage gear factor
These functions are used to enter the gear factor for the top and bottom roller drive
Rotational direction
This function is used to set the appropriate rotational direction of the drive.
Parameter menu
With this function, a menu appears for setting the machine parameters, see Chapter 13.15
Parameter settings.
Machines without Puller
Machines with Puller
Upper roller
Lower roller
Puller
Upper roller
Lower roller
