19
Controls
7.05 Triple foot switch (optional)
● If the foot switches 1 to 3 are pressed,
the value for the speed difference bet-
ween the top and bottom feed roller is
changed step by step or reset.
1 = Reduce speed of top feed roller
step by step
2 = Increase speed of top feed roller
step by step.
3 = Reset speed difference between
the top and bottom feed rollers.
The speed difference between
top and bottom feed rollers is
shown in % on the control
panel.
Fig. 7 - 04
Fig. 7 - 05
7.04 Foot switch (optional)
● Move to the next sealing section in the
programmed sealing operation by pres-
sing foot switch 1.
Alternatively, a knee switch can
be ordered for this function.
1
1
2
3
