14 Circuit diagrams
14
.01 Reference list for the Circuit diagrams 95-211 948-95
A1 Control device PCS 2002
A2 Control panel (BDF T1 or P1)
A3 Floppy disk (option)
B1 Temperature sensor
B2 Pedal
M1 DC motor bottom roller
M2 DC motor top roller
M3 Puller motor (option)
E1 Bottom roller
E3 Nozzle/wedge engaged
E4 Front nozzle/wedge
E5 Hot air heating element
E6 Hot wedge heating element (1)
E7 Hot wedge heating element (2)
E10 Nozzle/wedge coding input
E11 Pressure controller
E14 Knee switch
E15 Increment differential
E16 Decrement differential
E17 Differential correction zero
E18 Key switch
AUS11 Monitorausgang Start / Stop
AUS12 Monitorausgang Fehler
IN1 Programmable input 1
IN2 Programmable input 2
F1 Fuse 16A L1
F2 Fuse 16A L2
G1 Power supply –24V, 5A
K1 Solid state relay
Q1 Main switch
Y1 Roller down
Y2 Additional blowing
Y3 Engage nozzle/wedge
Y4 Front nozzle/wedge
Y5 Closing cylinder puller (option)
Y50 Air volume
Y51 Roller pressure
Z1 Mains fi lter
