Adjustment
103
13.15.02 List of parameters
Only appropriately trained personnel is authorized to alter the set values
in the parameters!
Parameter Discription Setting range Set value
Sequence
continue
0: Process sequence program as quick key selection.
1: Sequence programs are automatically relayed.
0 - 1 1
Enable
Manprog
0: Manual data records cannot be saved or loaded.
1: Manual data records can be saved and loaded as
programs in area 130..149.
(see chap. 11.05)
0 - 1 0
VQLIM if positive: error #17 boundary stress
if negative: max. stress at standstill
+/- 2400 500
Powertest Only on the 8320-010
0: function deactivated
1: display of heating input at hot wedge
0 - 1 0
Stop with IN1 0: IN1 as zone forwarding condition in programs
1: digital Stop signal at input IN1
0 - 1 0
Start with IN2 0: IN2 as zone forwarding condition in programs
1: digital Start signal at input IN2
0 - 1 0
Temp sensors Only on the 8320-020
Number of temperature sensors
1 -2 1
Flow control 0: function deactivated
1: Air volume monitoring
0 - 1 0
Enable Puller Option
0: No additional puller installed
1: Additional puller activating
0 - 1 0
LinkRollerPuller Only visible with active puller
0: Puller is lifted or lowered with puller button
1: Puller follows the movement of upper roller
0 - 1 0
