54
Heat sealing
10.06 Programmed heat sealing with sequences
In the headline, in addition to the sequence number of the selected sequence, the num-
ber of zones, the current zone and the comment for the current program are displayed. For
the current zone all heat-sealing parameters are displayed. The heat-sealing parameters have
been stipulated during programming and cannot be processed without changing the pro-
gram. In addition, in the case of heat sealing with sequence programs, the individual pro-
grams belonging to the sequence are displayed, and the current program is shown here as
an inverse symbol.
● Select the desired sequence, see Chapter 9.02 Selecting the production type.
Description of the functions
Program selection
The function opens the menu for entering the program number or for choosing the
production type, see Chapter 9.02 Selecting the production type.
Notepad
This function opens the notepad with program details about the heat-sealing tools
to be used.
Heat sealing program
Press this function to select the appropriate heat sealing program.
Start
(This function appears, when the top feed roller is lowered.)
This function is used to call up the sealing start, analog to pedal function "+2", also see
Chapter 7.03 Pedal.
Feed roller up/down
This function is use to raise or lower the top feed roller, depending on its position, analog to
the pedal functions "-1" and "+1", also, see Chapter 7.03 Pedal
Feed rollers in reverse
This function can be used to call up the reverse running function of the feed rollers.
Break
This function is used to switch off the temperature control of the heating element.
The heating element cools down.
Input menu
This function is used to call up the "Input" mode, see Chapter 11 Input.
Example 1
