69
Input
Parameter Values [init] Function
Sequence continue 0,[1] 1: Sequence programs are forwarded
0: Sequence programs as quick key selection
Enable Manprog [0],1 1: manual datasets can be stored and loaded back as program 130..149
0: the function is disabled
VQLIM +/-2400 Do not change value 500
Stop with IN1 [0],1 1: digital Stop signal at input IN1
0: IN1 as zone forwarding condition in programs
Start with In2 [0],1 1: digital Start signal at input IN2
0: IN2 as zone forwarding condition in programs
Temp sensors [1],2 Numer of temperature sensors
Flow control [0],1 1: Air volume monitoring
0: function deactivated
Enable Puller [0],1 1: Additional puller activating
0: No additional puller installed
LinkRollerPuller [0],1 1: Puller follows the movement of upper roller
0: Puller is lifted or lowered with the puller button
(Only visible with active puller)
Progr.sealing with Sequences
Y4
Program selection
Sequences
Notes
load manual
130 .. 149
store manual
130 .. 149
select manual
sealing
(
If enebled with parameter Enable Manprog = 1
)
Temperature Rollerpressure Rollerspeed
Staring
delay
Feed difference
Further parameter
Preheat rollers Positioning
the nozzle
Block rollers Program managment
Parameters of manual sealing exist separately
.
Parameters of programmed sealing and programmed sealing with sequences
are entered in „Creating/altering a program“.
Copy Delete Machine
data /
configuration
Format
Local settings
Rights of access
D, GB, F, E, I mm, inch...
°C, °F
UnitsLanguage
Further parameters
Conclude
Discard Save Program Program
save as...
Airvolume /
nozzle type
Nozzle typ
Preheat rollers
Nozzel typ
Deceteration
low middle high
Acceleration values
low middle high
Further parameters
Deceteration
low middle high
Acceleration values
low middle high
Staring
delay
backward
Y4 activated:
Nozzle travels
forward/back
Y4 deactivated:
Nozzle remains in
forward position
