5 Installation
5.1 Prerequisites for optimising measurement
To optimise pumping and measurement speed:
● Use pipe with a diameter equal to the diameter of the detector's inlet. The pipes should
be as short as possible and completely sealed.
● Do not use plastic hoses such as compressed air pipes.
● Check that the connected part/installation is impermeable to tracer gas.
● Test only clean, dry parts/installations with no trace of water, vapour, paint, detergent
or rinsing products.
● Test that the entire line is completely sealed when the detector is attached to the
pumping circuit, to ensure that the connections are correct (pump, pipe, valves, etc.).
5.2 Operating conditions
5.3 Set-up
The leak detector must be installed on a flat, horizontal surface, supported by its feet,
with the detector's inlet port on the top.
Choose the location for set up according to the dimensions of the detector: chapter -
Technical Characteristics (see 11.2).
Move the detector with a hoist, using the handling devices (see 3.1).
DANGER
Explosion hazard.
For detecting leaks with "hydrogen" tracer gas, the operator must use hydrogenated ni-
trogen (mix of 95 % N
2
and 5 % H
2
).
NOTICE
Risk of pollution from solid substances
When applications generate particles, we recommend protecting the detector's inlet.
Install a inlet filter and possibly a Bypass (see 10).
NOTICE
Detector ventilation
If there is insufficient ventilation, overheating could cause damage to the components:
Comply with the ambient operating temperature.
Do not obstruct the air vents.
Leave a gap of 70 mm around the air vents.
Environmental conditions
Ambient operating temperature (Hard Vacuum test) + 0 °C to + 45 °C (Wet Model)
+ 0 °C to + 35 °C (Dry Model)
Ambient operating temperature (Sniffing test) + 0 °C to + 35 °C (Wet Model)
+ 0 °C to + 35 °C (Dry Model)
Storage temperature - 20 °C to + 55 °C
Maximum hydrometry 85%, without condensing
Maximum magnetic field 3 mT
