PFT G 4 X - Power Values Pump Unit D6-3

Mixing pump G 4 X smart Overview - Operation and service
Technical data
12 2021-08-12
Duration
Detail Value Unit
Max. operating time at a stretch
8
hours
Electrical details
Detail Value Unit
voltage, three-phase current 50 Hz 400 V
Power consumption, max. 32 A
Power input, max. 7.2 kW
Fuse protection, at least 3 x 25 A
Speed pump motor approx. 385 / 400 rpm
Speed star wheel motor 28 / 12 rpm
4.4 Power values Pump unit D6-3
Pump capacity D6-3 (DE)
Compressor output LK 250
Compressor output K2 N
Detail Value Unit
Pump capacity, approx. 22
l/min at
385 rpm
Operating pressure, max. 30 bar
Grain size max. 2 mm
Feed range *, max. at 25 mm ∅
20
m
Feed range *, max. at 35 mm ∅ 40 m
Compressor output 0.25 Nm³/min
* reference value depending on conveying height, pump condition and version,
mortar quality, composition and consistency
