Mixing pump G 4 X smart Overview - Operation and service
Dimension sheet
14 2021-08-12
7 Dimension sheet
Fig. 2: Dimension sheet
8 Name plate
Fig. 3: Name plate
The type plate is located at the right bottom of the hopper and
includes the following information:
Manufacturer
Type
Year of manufacture
Machine number
Permissible operating pressure
9 Quality Control sticker
Fig. 4: Quality Control sticker
The following details can be found on the Quality Control sticker:
CE confirmed as per EU directives
Serial no / serial number
Controller / signature
Date of control
