PFT G 4 X - Assembly; Overview

Mixing pump G 4 X smart Overview - Operation and service
Assembly
2021-08-12 15
10 Assembly
10.1 Overview
1 2 3
13 12 11 10 9
Fig. 5: Table of the assembly groups
1. Pump motor
2. Motor protection handle
3. Deflector plate (accessory)
4. Protective grille with sack opener
5. Hopper
6. Air compressor
7. Carrying handle
8. Double stop castor
9. Water sampling valve
10. Water tap
11. Connection for mortar hose
12. Mortar pressure gauge
13. Mixing tube
14. Castor
15. Power connection at control cabinet
16. Control cabinet
17. Locking lever
4
5
6
7
8
17
16
15
14
