Mixing pump G 4 X smart Overview - Operation and service
Measures in case of power cut
44 2021-08-12
40 Measures in case of power cut
40.1 Main switch to position “0“
1
Fig. 68: Selector switch position “0”
1. Close the air tap at the spraying gun.
2. Turn the main switch (1) to position "0".
3. Switch off the air compressor at the red switch.
4. Let qualified staff check the power supply.
40.2 Relieve mortar pressure
2 1
Fig. 69: Check mortar pressure
DANGER!
Overpressure on the machine!
When opening machine parts they can open in an
uncontrolled manner and injure the operator.
Open machine only when the pressure is at "0 bar".
DANGER!
Risk of injury from discharged mortar!
Discharged mortar may lead to injuries to eyes and
face.
Therefore:
Never look into the spraying device.
Always wear protective goggles.
Always position yourself in such a way that you
are not hit by the mortar being discharged.
1. Open the air tap at the spraying gun.
2. Check the mortar pressure gauge (1) if the mortar pressure has
lowered to "0 bar". If required relieve the mortar pressure by lightly
loosening the nuts (2). In doing so, cover the work area with film.
3. Firmly tighten the nuts again.
