Technical Specifications and Connection Facilities
EN 2 DVDR70 & DVDR75/0x11.
1. Technical Specifications and Connection Facilities
1.1 Diversity Matrix for sets with drive VAE8020
(AV2)
Remarks:
<VN03 ... This module is used in sets with production codes VN01 and VN02. Please see the type plate of the set for the production code.
>VN02 ... This module is used in sets with production code VN03 and higher.
E1 ... Digital Board Chrysalis Version Euro 1 for sets with DV input
E2 ... Digital Board Chrysalis Version Euro 2 for sets without DV input
AL E1/PS ... Analog Board version A-Lead Euro 1, used from production start onwards.
AL E2/PS ... Analog Board version A-Lead Euro 2 for UK, used from Production Start onwards.
The Analog Board versions "AL Ex/PS" are based on the PWB layout code 3103 603 3033.
This layout code can also be seen on the underside of the Analog Board in the copper near the power supply part.
AL E1 ... Analog Board version A-Lead Euro 1 replaces "AL E1/PS" at a certain production date.
AL E2 ... Analog Board version A-Lead Euro 2 for UK replaces "AL E2/PS" at a certain production date.
The Analog Board versions "AL Ex" are based on the PWB layout code 3103 603 3028.
The main difference to the Analog Board used at production start is the used audio digital/analogue converter; see Analog Board circuit
diagram 9.
1.2 Diversity Matrix for sets with drive VAD8031
(AV3)
Sets with VAD8031 can be identified by the production code
starting with VN1A, (then VN1B, VN1C...) and by the presence
of a set fan.
Type DVDR 75/001 75/021 75/051 70/001 70/021 70/051
Version
A' Lead X X X
A Lead X X X
DVIO DVIO 1.8 <VN05 <VN05 <VN05
Digital Board
(Chrysalis) 2.1
E1 >VN04 >VN04 >VN04
E2 >VN04 >VN04 >VN04
Digital Board
(Empress) 1.5
E1 <VN05 <VN05 <VN05 <VN05 <VN05 <VN05
Basic Engine VAE 8020 XXXXXX
UP Sub AL E1 X X X X X X
Analog-Board
3103 603 3033
AL
E2/PS
<VN04 <VN04
AL
E1/PS
<VN03 <VN04 <VN03 <VN04
3103 603 3028
AL E2 >VN03 >VN03
AL E1 >VN02 >VN03 >VN02 >VN03
Display Board DC1 AL X X X X X X
Type DVDR 75/001 75/021 75/051 70/001 70/021 70/051
Version
A' Lead X X X
A Lead X X X
Digital Board
(Chrysalis) 2.1
E1 /AV3 X X X
E2 /AV3 X X X
BasicEngine VAD 8031 X X X X X X
UP Sub AL E1/AV3 X X X X X X
Analog-Board
use PWB drawing
603 3028
AL E2/AV3 X X
AL E1/AV3 X X X X
Display Board DC1 ALXXXXXX
