Technical Specifications and Connection Facilities
EN 5DVDR70 & DVDR75/0x1 1.
1.13 PCB Locations
Remarks:
The EPG Board and the In/Out Extension Board IOE are only
used in the DVDR80.
The DVIO Board is only present in the DVDR75 and only in
combination with the Digital Board 1.5 (Empress). It is not
present in DVDR75 with Digital Board 2.1 (Chrysalis).
DVIO Board
EPG Board
Digital Board
Display Board
Basic Engine
Analog Board
IOE Board
Up Sub Board
TR 06002_001
