Diagnostic Software
EN 59DVDR70 & DVDR75/0x1 5.
The paths that are available for video routing and their description (Euro region):
Example
DD:> 712 01
71200: Video routing on the Analogue Board OK.
Test OK @
Route Audio
Nucleus Number: 713
Description
This nucleus routes the audio on the analogue board to the
destination determined by the input parameters
The paths that are available for audio routing and their
description (Europe version)
EXAMPLE DD:> 713 00
71300: Audio routing on the Analogue Board OK.
Path ID Description
00 Input signal is VIDEO(CVBS) from digital board and will be re-routed back to the digital
board.
01 Input signal is from FRONT VIDEO(CVBS) IN and will be routed to the digital board.
02 No Routing.
03 Input signal is from FRONT S-VIDEO(Y/C) and will be routed to the digital board.
04 No Routing.
05 Input signal is CVBS from SCART1 and will be routed to the digital board.
06 Input signal is CVBS from SCART2 and will be routed to the digital board.
07 Input Signal is CVBS from Digital Board and it will be routed to Scart1 and Scart2.
08 Input signal is VIDEO(CVBS) from ANTENNA IN and will be routed to SCART2.
09 Input signal is VIDEO(CVBS) from SCART1 and will be routed to SCART2.
10 Input signal is VIDEO(CVBS) from SCART2 and will be routed to SCART1.
11 Signal path is routed Fast Blank from Scart2 pin16 and will be routed Scart1 pin16
12 Input Signal is YC from Digital Board and it will be routed to Scart1.
13
14 No Routing.
15 Input Signal is CVBS from TUNER and it will be routed to Digital .
16 No Routing.
17 Input Signal is routed from digital board YC to REAR S-VIDEO(YC) OUT
18 Signal path is routed from digital board RGB to RGB SCART1 and from digital board CVBS
to digital board CVBS.
19 No Routing.
20 Input RGB Signal is routed from Digital Board to SCART1(RGB),Input CVBS Signal from
Digital Board to Digital Board and Fast Blanking Signal from Scart 2 to Scart1.
21 Input Y/C Signal from Digital Board is routed to Rear Y/C Connector and Input Y/c Signal
from Front Y/C connector is routed to Digital Board.
Path ID Description
00 Input signal is from FRONT AUDIO IN and will be routed to the digital board.(This is done so
that nucleus 901 works)
01 Input signal is from FRONT AUDIO IN and will be routed to the digital board.
02 No Routing.
03 Input signal is AUDIO from SCART1 and will be routed to the digital board.
04 Input signal is AUDIO from SCART2 and will be routed to the digital board.
05 No routing.
06 No routing.
07 Input Audio signal is from the digital Board and it will be routed to the Scart 1 and Scart2
08 Input AUDIO signal from TUNER and will be routed to SCART2.
09 Input signal is AUDIO from SCART1 and will be routed to SCART2.
10 Input audio signal from Scart2 is routed to Scart1.
11 Input Audio signal is routed from DVIO to Scart2.
12
13 No Routing.
14 Input is Audio Signal from DVIO and it will be routed to Digital Board.
15 Input is Audio Signal from TUNER and it will be routed to Digital Board..
16 No routing.
17 No Routing.
18 Input signal is from FRONT AUDIO IN and will be routed to SCART2.
21 Input signal is from FRONT AUDIO IN and will be routed to the digital board.(This is done so
that nucleus 909.1 works)
