Diagnostic Software
EN 66 DVDR70 & DVDR75/0x15.
Digital Video Input Output (DVIO)
User Input The input to select, see table below.
1 CVBS_Y_IN_A
2 CVBS_OUT_B
3 CVBS_Y_IN_B
4 CVBS_Y_IN_C
6 C_IN
8 G_IN
9 Y_IN
13 B_IN
14 U_IN
18 R_IN
19 V_IN
Example DS:> 604 1
060400:
Test OK @
Nucleus Name DS_DVIO_LinkDevTypeGet
Nucleus Number 700
Description Get the device (revision) type information of the 1394 Link layer IC
User Input None
Example DS:> 700
070000: Device type of the link layer IC: ffc00301
Test OK @
Nucleus Name DS_DVIO_PhyDevTypeGet
Nucleus Number 701
Description Get the device (revision) type information of the 1394 Physical layer IC
User Input None
Example DS:> 701
070100:
Device type of the phy layer IC: 0
Test OK @
Nucleus Name DS_DVIO_LinkCommunication
Nucleus Number 702
Description Check the accessibility of the 1394 Link layer IC by writing to and reading from a specific
address
User Input None
Example DS:> 702
070200:
Test OK @
Nucleus Name DS_DVIO_PhyCommunication
Nucleus Number 703
Description Check the accessibility of the 1394 Physical layer IC by writing to and reading from a spe-
cific address
User Input None
Example DS:> 703
070300:
Test OK @
Nucleus Name DS_DVIO_Routing
Nucleus Number 704
Description Route a DV stream containing an audio and video signal through the physical and link layer
ICs to the Chrysalis
User Input None, test works for both NTSC and PAL
Example DS:> 704
070400:
Test OK @
Nucleus Name DS_DVIO_DetectNode
Nucleus Number 705
Description Check whether a DV node can be detected by the hardware
User Input None, test works for both NTSC and PAL
