Diagnostic Software
EN 68 DVDR70 & DVDR75/0x15.
Basic Engine (BE)
Nucleus Name DS_PSCAN_Routing
Nucleus Number 806
Description Route a video signal from the host processor through the progressive scan ICs to the pro-
gressive scan output of the set.
Note: to route the progressive scan to the output of the set, first call nucleus 1112 with pa-
rameter 0 (video routing on analogue board).
User Input None
Example DS:> 806
080600:
Test OK @
Nucleus Name DS_PSCAN_DevTypeGetDeinterlacer
Nucleus Number 807
Description Get the device (revision) type information of the progressive scan deinterlacer.
User Input None
Example DS:> 807
080700:
Chip name : 2300
Chip version : 1
Test OK @
Nucleus Name DS_PSCAN_CommunicationDeinterlacer
Nucleus Number 808
Description Check the communication between the IIC controller of the chrysalis and the progressive
scan Deinterlacer-IC
User Input None
Example DS:> 808
080800:
Test OK @
Nucleus Name DS_BE_CommunicationEcho
Nucleus Number 900
Description Check the communication between the digital board and the basic engine by issuing an
echo command over the S2B interface
User Input None
Example DS:> 900
090000:
Test OK @
Nucleus Name DS_BE_Reset
Nucleus Number 901
Description Reset the basic engine
User Input None
Example DS:> 901
090100:
Test OK @
Nucleus Name DS_BE_VersionGet
Nucleus Number 903
Description Get the version of the basic engine and that of the optical unit
User Input None
Example DS:> 903
090300: BE version = 20.09.18 Optical unit version = 3C.00.09.41.08
Test OK @
Nucleus Name DS_BE_GetSelftestResult
Nucleus Number 902
Description Return the self-test results through the service port
User Input None
Example DS:> 902
090200:
Test OK @
