Diagnostic Software
EN 83DVDR70 & DVDR75/0x1 5.
Electronic Program Guide Board (EPGB)
PCMCIA INTERFACE (PCMCIA)
Example DS:> 1228
Settings ID: 6D7920626F61726400020300010101020101000020080000
Board name: my board
Hardware ID: 0
Codec IC: PNX7100_MF2
Video Input Processor IC: SAA7118
Progressive Scan Deinterlacer IC: None
Progressive Scan Denc IC: ADV7196
I-Link physical layer circuit IC: PDI1394P25
I-Link link layer circuit IC: PDI1394P40
Audio clock: Clock scheme 1
Bit engine connector: available
IDE connector 1: available
IDE connector 2: not available
PCI connector: not available
RAM size 32MByte
ROM size (NOR FLASH bank 1) 8MByte
ROM size (NOR FLASH bank 2) Not available
ROM size (NAND FLASH) Not available
Bit Engine: AV 2.0
122800:
Test OK @
Nucleus Name DS_SYS_SettingsGet
Nucleus Number 1229
Description Get the digital board diversity settings string that is programmed in the BROM on the
digital board.
User Input None.
Example DS:> 1229
122900: 6D7920626F61726400020300010101020101000020080000
Test OK @
Nucleus Name DS_SYS_AudioLoopThroughStart
Nucleus Number 1230
Description Description: The audio input is routed from the an input to all outputs. Input is set with
the routing nucleus 1113. All outputs are enabled.
User Input None.
Example DS:> 1230
123000:
Test OK @
Nucleus Name DS_SYS_AudioLoopThroughStop
Nucleus Number 1231
Description Stop routing the audio input to all the outputs
User Input -
Example DS:> 1231
123100:
Test OK @
Nucleus Name DS_EPGB_VersionGet
Nucleus Number 1300
Description Returns the version of the EPG board.
User Input None
Example DS:> 1300
130000:
Version : 6.1.9
Test OK @
Nucleus Name DS_PCMCIA_Reset
Nucleus Number 1400
Description Reset the PCMCIA device by sending a reset command through IDE
Example DS:> 1400
140000:
Test OK @
