Cleaning and Sterilization
Maintenance, Cleaning & Troubleshooting
11-13
3 Test the transceiver:
a. Put fresh batteries in the transceiver (without a leadset
attached) and close the battery door
Result: All six lead lights should flash, and one light
should remain on.
b. Attach a leadset to the ECG port, and attach an SpO
2
sensor to the SpO
2
port. If an ECG simulator is avail-
able, attach the ECG leads to the simulator and the SpO
2
sensor to yourself. At TeleMon, set the SpO
2
sample
rate to Continuous.
Result: An ECG trace and SpO
2
information should be
visible on the Information Center display. All transceiv-
er lights should be off.
c. Disconnect the Right Arm lead for standard ECG or the
“I” electrode for EASI.
Result: The RA LED or the “I” lead LED should turn
on, and a Leads Off INOP should appear on the display
at the Information Center.
d. Reconnect the electrode.
4 a. Connect the transceiver to TeleMon and observe the
ECG waveform and SpO
2
numerics on the TeleMon dis-
play.
Result: The ECG waveform and SpO
2
numerics should
be displayed on the TeleMon screen.
Step Action
