Description of the controllers
107708_en_08 PHOENIX CONTACT 15 / 112
Axioline F local bus There is an interface to the Axioline F local bus on the bottom of the controller. Bus base
modules are used to carry the communications voltage and the bus signals from the con-
troller through the Axioline F station. A bus base module is supplied with the controllers.
Up to 63 Axioline F modules can be connected to the controllers. The modules are con-
nected to the right of the controller. The maximum number of modules that can be operated
depends on the current consumption of the modules. The total current consumption of all
devices connected to the controller must not exceed the maximum current that the control-
ler supplies for the local bus.
Left-alignment of
Axioline F extension
modules
– You can connect one Axioline F extension module to the left of the AXC F 2152 using
the AXC BS L 2 bus base module.
– You can connect one AXC F XT IB Axioline F extension module to the left of the
AXC F 3152 using the supplied AXC BS L 30 bus base module. Connection of the left-
alignable AXC F XT ETH 1TX Ethernet interface is not supported yet.
– Axioline F extension modules cannot be aligned to the left of the AXC F 1152.
The following left-alignable Axioline F extension modules are currently available:
– AXC F XT ETH 1TX (Order No. 2403115):
Left-alignable Ethernet interface
– AXC F XT IB (Order No. 2403018):
Left-alignable INTERBUS master for the connection of up to 255 INTERBUS remote
bus devices
For additional information on how to integrate your controller as a PROFINET controller
or device, please refer to the PLCnext Engineer online help.
NOTE: Electronics may be damaged when overloaded
Observe the current consumption of each device when configuring an Axioline F station.
The current consumption is specified in each module-specific data sheet and may vary.
The possible number of devices that can be connected depends on the structure of the
Axioline F station.
Please note:
The AXC BS L 2 bus base module is not supplied with the AXC F 2152. For the ordering
data for the bus base module, please refer to Section “Ordering data” on page 91.
For the INTERBUS master, please note:
The left-alignable AXC F XT IB INTERBUS master and the AXC F IL ADAPT Inline adapt-
er terminal cannot be used simultaneously.
