Phoenix Contact AXC F 3152 User Manual

AXC F X152
24 / 112
PHOENIX CONTACT 107708_en_08
3.8.2 Printing
AXC F 1152 and AXC F 2152 controller printing
AXC F 3152 controller printing
Figure 3-8 AXC F 1152 and AXC F 2152 controller printing
1 Order number and
order designation
2 MAC address
3 QR code for UUID
4 Administrator password
5 QR code for connecting to the PLC-
next Community
6 UUID for connecting to
PROFICLOUD
7 QR code for administrator password
8 Year of manufacture
SD-CARD
R
X4
MAC Addr.: 00.A0.45.9D13.BC
Ord. No. 2404267
AXC F 2152
X1
X2
UL
a1 b1
b2b1
scan here
for easy start up
BF-C
BF-C
SF
BOOT
EXT
FA I L
RUN
DBG
D
E
PLCnext Technology
Designed by PHOENIX CONTACT
password: 12345678
www.plcnext-community.net
UUID: 1234j4789G12345j4789G1234j4789G
U
LISTED
IND.CONT.EQ.FOR.
HAZ.LOC.
E366727
Class I, Zone 2, AEX nA IIC T4/EX nA IIC Gc T4
Class I, Division 2, Groups A, B, C, and D T4
U = 19.2 - 30 VDC
Imax : 442 mA
Amb.Temp.: -25°C < Ta < 60°C
4
6
7
1
2
5
3
XX
8
Figure 3-9 AXC F 3152 controller printing
1 Order number and
order designation
2 QR code for UUID
3 UUID for connecting to
PROFICLOUD
4 QR code for administrator password
5 Administrator password
6 Year of manufacture
UL
a1 b1
b2b1
X2
BF-C
BF-C
SF
BOOT
EXT
FAIL
RUN
DBG
D
E
X1
X3
SD-CARD
RUN/PROG
X4
R
STOP
MRESET
UUID: 1234j4789G12345j4789G1234j4789G
password: 12345678
2
3
4
plcnextcommunity.com
PLCnext Control
Ord.-No 1069208
AXC F 3152
XX
1
5
6
