Phoenix Contact AXC F 3152 User Manual

AXC F X152
20 / 112
PHOENIX CONTACT 107708_en_08
3.7.2 The controller as a PROFINET controller in a PROFINET
network
Figure 3-4 shows the example of the AXC F 3152 controller as a PROFINET controller in a
PROFINET network.
Figure 3-4 Example: AXC F 3152 controller as PROFINETcontroller
Key:
A PROFINET controller (AXC F 1152, AXC F 2152 or AXC F 3152)
B PROFINET device and switch (in the example: controller with connected Axioline F I/O
modules)
UL
a1 b1
b2b1
UL
a1 b1
b2b1
UL
a1 b1
b2b1
1357
2468
MODE
ACT
SPD
FD
US1 US2
FAIL
LINK
Mode
12345678
X12
V.24
X9 X10
US1 GND US2 GND R1 R2
X10
MAC
Address
FL SWITCH SMSC 8GT
Ord.. No.2891123
A
PROFINET
B
PROFINET
B
B
For additional information on how to integrate the controller as a PROFINET controller into
a PROFINET network, please refer to the PLCnext Engineer online help.
