Ordering data and technical data
107708_en_08 PHOENIX CONTACT 93 / 112
14.3 Technical data of the AXC F 1152 and AXC F 2152
Dimensions (nominal sizes in mm)
Width 45 mm
Height 126.93 mm
Depth 75 mm
Note on dimensions The depth applies when a TH 35-7.5 DIN rail is used
(in accordance with EN 60715).
General data
Color Gray
Weight 215 g
Design Axioline
Mounting method DIN rail mounting
Operating system Linux
RAM 512 MByte DDR3 SDRAM
Real-time clock Yes
Ambient conditions
Ambient temperature (operation) -25°C ... 60°C up to 2000 m above sea level (note derating)
-25°C ... 55°C up to 3000 m above sea level (note derating)
≤55°C (with max. 1 A on U
Bus
)
>55°C ... 60°C (only in conjunction with an Axioline F power
module AXL F PWR 1H (Order No. 2688297))
Ambient temperature (storage/transport) -40°C … 85°C
Permissible humidity (operation) 5% ... 95% (in accordance with DIN EN 61131-2)
Permissible humidity (storage/transport) 5% ... 95% (in accordance with DIN EN 61131-2)
Air pressure (operation) 70 kPa ... 106 kPa (up to 3000 m above sea level)
Air pressure (storage/transport) 58 kPa ... 106 kPa (up to 4500 m above sea level)
Degree of protection IP20
Protection class III, IEC 61140, EN 61140, VDE 0140-1
Vibration (operation) 5g
