Ordering data and technical data
107708_en_08 PHOENIX CONTACT 99 / 112
Vibration (storage/transport) 5g
Shock 30g, 11 ms period, half-sine shock pulse, in accordance with
IEC 60068-2-27
Shock (operation) 10g (bump endurance test in accordance with
DIN EN 60068-2-27)
Ambient conditions
Connection data
Designation Axioline F connector
Connection method Push-in connection
Conductor cross section rigid/flexible 0.2 mm² ... 1.5 mm²
Conductor cross section [AWG] 24 ... 16
Stripping length 8 mm
Processor
Processor Intel
®
Atom™ x5-E3930 1.3 GHz Dual Core
Axioline F local bus interface
Number of interfaces 1
Connection method Bus base module
Transmission speed 100 Mbps
Electrical isolation No
Number of supported devices Max. 63
Ethernet interface
Number of interfaces 3
Connection method RJ45 jack
Note on the connection method Auto-negotiation and auto-crossing
Bus system RJ45
Transmission speed 10/100/1000 Mbps
Transmission length 100 m, max.
Transmission physics Ethernet in RJ45 twisted pair
System limits
Number of supported devices Max. 63 (per station)
Number of local bus devices that can be connected Max. 63 (observe current consumption)
NOTE: Electronics may be damaged if overloaded
Note the logical current consumption of each device when configuring an Axioline F station. This is specified
in every module-specific data sheet. The current consumption can differ depending on the individual module.
The permissible number of devices that can be connected therefore depends on the specific station structure.
PROFINET
Device function PROFINET controller, PROFINET device
Number of supported devices Max. 128 (on PROFINET controller)
Specification Version 2.3
