AXC F X152
100 / 112
PHOENIX CONTACT 107708_en_08
Conformance class A
Update rate Min. 1 ms (32 devices)
Min. 4 ms (128 devices)
Number of slots 1
Device ID 0158
hex
PROFINET
Communications voltage U
L
feed-in (the supply of the Axioline F local bus U
Bus
is generated from U
L
)
Supply voltage 24 V DC
Supply voltage range 19.2 V DC ... 30 V DC
Current consumption Typ. 260 mA (with no I/Os and U
L
= 24 V)
Typ. 504 mA (with 1 A at U
Bus
for the I/Os and U
L
= 24 V)
Power consumption Typ. 6.24 W (with no I/Os)
Typ. 12.1 W (with 1 A at U
Bus
for the I/Os and U
L
= 24 V)
Surge protection for supply voltage Electronic
Polarity reversal protection for supply voltage Electronic
NOTE: Electronics may be damaged if overloaded
Provide external protection for the 24 V U
L
range. If you use a fuse, the power supply unit must be capable of
supplying four times the nominal current of the fuse. This ensures that the fuse trips reliably in the event of a
fault.
Axioline F local bus supply (U
Bus
)
Supply voltage 5 V DC (via bus base module)
Power supply 1A
Real-time clock
Real-time clock accuracy 0.7 s/day = 8 ppm at 25°C
Power reserve 14 days at 25°C
Error messages to the higher-level controller or computer system
None
Programming
Programming tool PLCnext Engineer (≥2020.3)
Eclipse
MATLAB
®
Simulink
®
Supported programming languages Programming in accordance with IEC 61131-3
C++
C#
Java
Manufacturer-specific
