Ordering data and technical data
107708_en_08 PHOENIX CONTACT 101 / 112
IEC 61131 runtime system
Module classification PLCnext Control for direct control of Axioline F I/Os
Type of application Distributed control technology
Application interface OPC UA
Number of data blocks Depends on mass storage
Cycle time 500 µs (for cyclic task)
Program memory 16 MBytes
Retentive mass storage 1 MByte
Mass storage 32 MBytes
Parameterization memory Min. 4 MB (depending on storage medium)
Conformance with EMC Directive 2014/30/EU
Immunity test in accordance with EN 61000-6-2
Electrostatic discharge (ESD)
EN 61000-4-2/IEC 61000-4-2
Criterion B, 6 kV contact discharge, 8 kV air discharge
Electromagnetic fields EN 61000-4-3 / IEC 61000-4-3 Criterion A, field strength: 10 V/m
Fast transients (burst) EN 61000-4-4/
IEC 61000-4-4
Criterion B, 2 kV
Transient overvoltage (surge)
EN 61000-4-5/IEC 61000-4-5
Criterion B; DC supply lines: ±0.5 kV/±0.5 kV (symmetri-
cal/asymmetrical), fieldbus cable shielding: ±1 kV
Conducted disturbance variables EN 61000-4-6/
IEC 61000-4-6
Criterion A, test voltage 10 V
Noise emission test according to EN 61000-6-3 Class B
Approvals
For the current approvals, please visit phoenixcontact.net/products.
