14 Technical Data
C-863 Mercury Controller MS205Equ Version: 2.0.0 95
Output on: Maximum Output
Voltage
Maximum Output
Current
Maximum Output
Frequency
Sub-D 15-pin (f):
pins 2 and 9
= operating voltage 2.5 A 36 kHz (PWM)
Sub-D 15-pin (f):
pins 3 and 11
5 V TTL 10 mA 36 kHz (PWM)
14.1.3 Ambient Conditions and Classifications
The following ambient conditions and classifications must be observed for the C-863:
Area of application For indoor use only
Maximum altitude 2000 m
Relative humidity Highest relative humidity 80% for temperatures up
to 31°C
Decreasing linearly to 50% relative humidity at 40°C
Storage temperature 0°C to 70°C
Transport temperature –25°C to +85°C
Overvoltage category II
Protection class I
Degree of pollution 2
Measurement category I
Degree of protection
according to IEC 60529
IP20
