3 Product Description
C-863 Mercury Controller MS205Equ Version: 2.0.0 11
In this Chapter
Features and Applications ........................................................................................... 11
Model Overview ........................................................................................................... 13
Product View ............................................................................................................... 13
Scope of Delivery ........................................................................................................ 15
Accessories ................................................................................................................. 16
Functional Principles ................................................................................................... 17
Communication Interfaces ........................................................................................... 18
Overview of PC Software ............................................................................................ 18
Stage Databases ......................................................................................................... 20
3.1 Features and Applications
The Mercury DC motor controller is the perfect solution for designing cost-efficient and
flexible positioning systems in which a precision stage is to be controlled with a PC or
a programmable controller. In addition to the C-863, the Mercury line comprises the
successful C-663 Mercury Step stepper motor controller. The controllers of the
Mercury line use the same command sets and can be networked with each other.
The product features of the C-863 include:
 RS-232 and USB interfaces
 Stand-alone operation
 Daisy chain networking for multi-axis operation
 Compatible and networkable with all Mercury line controllers, including
Mercury Step
 Joystick connection for manual operation
 Non-volatile macro memory
 Parameter changing during operation
 TTL inputs for limit and reference point switches
 Control signal for motor brake
 Programmable in-/outputs
3
Product Description
