PI C-863 User Manual

3 Product Description
C-863 Mercury Controller MS205Equ Version: 2.0.0 15
Labeling Type Function
DC motor
only
Sub-D 15(f)
(p. 97)
Stage connection Only for DC motors!
 Output of PWM signals for the stage
 Input of the signals of the incremental position sensor
 Input of the signals from the limit switches and reference point
switch
Screw and flat
washer
Ground connection (p. 34)
If potential equalization is required, the screw can be connected to
the grounding system.
3.4 Scope of Delivery
Order
Number
Items
C-863.11 Mercury DC motor controller
C-890.PS Wide-Range Power Supply for Mercury Controller
3763 Power cord
C-815.34 RS-232 Null-Modem Cable, 3 m, 9/9-pin
C-862.CN Network Connecting Cable for Mercury, 30 cm
000014651 USB cable (type A to Mini-B) for connection to the PC
C-663.CD1 Mercury product CD with software and user manuals for Mercury products
The Mercury product CD applies to the C-663.11 and the C-863.11.
MS205Dqu Short version of the user manual for the C-863.11
