C-863 Mercury Controller MS205Equ Version: 2.0.0 43
7.2.2 Controller Address
Address* S1 S2 S3 S4
1 ON ON ON ON
2 ON ON ON OFF
3 ON ON OFF ON
4 ON ON OFF OFF
5 ON OFF ON ON
6 ON OFF ON OFF
7 ON OFF OFF ON
8 ON OFF OFF OFF
9 OFF ON ON ON
10 OFF ON ON OFF
11 OFF ON OFF ON
12 OFF ON OFF OFF
13 OFF OFF ON ON
14 OFF OFF ON OFF
15 OFF OFF OFF ON
16 OFF OFF OFF OFF
*Factory settings are shown in bold.
INFORMATION
A unique address must be set for each controller in a daisy chain network. In doing
so, one of the controllers must have the address 1. This controller does not have to
be the one directly connected to the PC.
A non-networked controller must have the address 1, if
it is to be used in PIMikroMove.
it is to be used in LabVIEW.
it is to be addressed with the PITerminal without specifying the target address; in
this case, in the responses of the C-863 target and sender addresses (p. 69) are
omitted as well.
