13 Customer Service
C-863 Mercury Controller MS205Equ Version: 2.0.0 91
For inquiries and orders, contact your PI sales engineer or send us an e-mail
(mailto:info@pi.ws).
If you have questions concerning your system, have the following information ready:
 Product codes and serial numbers of all products in the system
 Firmware version of the controller (if present)
 Version of the driver or the software (if present)
 Operating system on the PC (if present)
The latest versions of the user manuals are available for downloading (p. 5) on our
website.
13
Customer Service
