34 Version: 2.0.0 MS205Equ C-863 Mercury Controller
6.3 Grounding the C-863
The C-863 is not grounded via the power supply connector.
If a potential equalization is required:
Connect the screw designated with the ground connection symbol (see figure)
on the rear panel of the case of the C-863 to the grounding system.
6.4 Connecting the Power Supply to the C-863
Motor damage due to excessively high operating voltage!
The output voltage on the Motor + and Motor - pins of the DC Motor only socket
can be as high as the supply voltage provided by the power supply. Stages without
PWM amplifier are connected to these pins and can be damaged by output voltage
that is too high.
Connect a power supply whose output voltage does not exceed the permissible
operating voltage of the stage.
Prerequisites
The power supply is not connected to the power socket via the power cord.
Tools and accessories
Included 15 V wide-range-input power supply (for line voltages between 100
and 240 volts alternating current voltage at 50 or 60 Hz) or other suitable
power supply that supplies 15 to 30 volts direct current voltage.
Connecting the power supply to the C-863
Connect the power supply to the 15-30 VDC connection of the C-863.
