3 Product Description
20 Version: 2.0.0 MS205Equ C-863 Mercury Controller
PC software
Operating
system
Short description
Recommended
use
PI Update
Finder
Windows
Checks the PI software installed on the PC. If
more current versions of the PC software are
available on the PI server, downloading is
offered.
For users who want to update
the PC software.
TMS320F28xx
Updater
Windows
Program for user support when updating
firmware.
For users who want to update
the firmware.
USB driver Windows Driver for the USB interface
For users who want to connect
the controller to the PC via the
USB interface.
3.9 Stage Databases
You can select a parameter set appropriate for your stage from a stage database in
the PC software from PI. The software transfers the values of the selected parameter
set to the volatile memory of the controller.
Database file name Editable? Description
PIStages2.dat
No, updates can be downloaded
from the PI website (p. 30).
Includes parameter sets for all standard stages
from PI; is automatically saved to the PC during the
installation of the software.
PI_UserStages2.dat
Yes, new parameter sets can be
created, edited and saved (p. 78).
Is created when you make a connection to your
stage using the PC software for the first time (i. e.
when selecting the stage in PIMikroMove or when
using the commands VST? or CST).
M-xxx.dat
No, you receive updates from our
customer service department
(p. 91).
Includes the parameter set for a custom stage, for
installation see "Installing a Custom Stage
Database" (p. 32).
You can find further information in the user manuals for PIMikroMove, PIStageEditor
and the PI GCS program library.
