C-863 Mercury Controller MS205Equ Version: 2.0.0 57
Prerequisites
You have read and understood the General Notes on Start-Up (p. 41).
PIMikroMove is installed on the PC (p. 29).
You have read and understood the PIMikroMove manual. The manual is
found on the product CD.
You have installed the latest version of the PIUserStages2.dat stage database
on the PC (p. 31).
If PI has provided you with a custom stage database for your stage, then you
have installed this database on your PC (p. 32).
You have installed the stage in the same manner as it will be used in your
application (corresponding load and orientation).
You have connected the stage to the C-863 (p. 36).
You have established communication between the C-863 and the PC with
PIMikroMove via TCP/IP, RS-232 or USB (p. 48).
Starting motions with PIMikroMove
1. If in PIMikroMove the Select connected stages step is displayed, select the
stage type of the stage connected:
If on the right in the window in the Controller axes list the correct stage type
is already listed in the Current stage type column:
− Click on OK.
If the listed stage type is not correct:
a) Mark the stage type in the Stage database entries list.
b) Click Assign.
c) Confirm the selection with OK to load the parameter settings for the
selected stage type from the stage database to the volatile memory of the
C-863.
