Refitting the driving pulley
- Preassemble the movable half-pulley with the
roller contrast plate by putting the rollers in their
housings with the larger support surface touching
the pulley according to the direction of rotation.
- Check that the roller contact plate does not have
flaws and is not damaged on the grooved edge.
- Mount the complete bushing unit on the driving
shaft.
- Fit the driven pulley/Clutch/belt unit on the en-
gine.
MP3 125 Engine
ENG - 15
