12-WAY INSTRUMENT CONNECTOR
Specification Desc./Quantity
1 5 Lighting
2 6 Battery positive
3 11 Earth
4 12 Live positive lead
Remote seat opening
Zeroing
- Remove the left side fairing to access the saddle
opening receiver control unit indicated in the pho-
tograph
- Remove the metal terminal and connect it to a
good earth point, or to terminal 7 (black), for at
least 10 seconds.
- In this operation all the remote controls stored in
the control unit will be deleted.
WARNING
THE CONTROL UNIT CAN PROGRAMME UP
TO 8 REMOTE CONTROLS.
Programming
Follow these steps to program the remote controls:
1. Insert the remote control key to be programmed in the steering lock key block.
Electrical system MP3 125
ELE SYS - 26
