positive probe to terminal No. 8 (Orange), and the
negative one to terminal No. 10 (Brown) (see fig-
ure).
Replace the control unit if there is no voltage; oth-
erwise, check the wiring connections between the
starter and the control unit.
Lights list
LIGHT BULBS TABLE
Specification Desc./Quantity
1 Low-beam bulb Type: HALOGEN (H1)
Power: 12V - 55W
Quantity: 1
2 High-beam light bulb Type: HALOGEN (H1)
Power: 12V - 55W
Quantity: 1
3 Helmet compartment light bulb Type: CYLINDRIC
Power: 12V - 5W
Quantity: 1
4 Rear turn indicator bulb Type: ALL GLASS
Power: 12V - 5W
Quantity: 2 RHS + 2 LHS
5 Rear tail light bulb Type: ALL GLASS
Power: 12V - 5W
Quantity: 1 RHS + 1 LHS
6 Stop light bulb Type: SPHERICAL
Power: 12V - 10W
Quantity: 2
7 License plate light bulb Type: ALL GLASS
Power: 12V - 5W
Quantity: 1
8 Front turn indicator bulb Type: ALL GLASS
Power: 12V - 10W
Quantity: 1 RHS + 1 LHS
9 Front tail light bulb Type: ALL GLASS
Power: 12V - 3W
Quantity: 1 RHS + 1 LHS
10 Instrument panel bulb Type: ALL GLASS
Power: 12V - 2W
Quantity: 4
Electrical system MP3 125
ELE SYS - 20
