Rear shock-absorber

REAR SHOCK ABSORBERS

Code Action Duration

1 003007 Rear shock absorber - Re-

moval and Refitting

2 003035 Shock absorber support and

brake calliper - Replacement

3 003077 muffler/rear shock absorber

support arm - Service
