PIAGGIO 633929(IT) - Top-Case; Rear; Handles and Top Side Fairings

Remove the two lower bracket retainers indicated
in the figure.
Disconnect the electric wiring and the fuel pipes.
See also
Footrest
Top-case
Rear
Remove the four fixing screws of the cover and
release it from the two leverages.
Handles and top side fairings
Remove the six screws indicated in the figure.
Chassis MP3 125
CHAS - 14
