Carry out the listed tests before delivering the vehicle.
Warning- be very careful when handling fuel.
Position the plastic cover supplied with the cou-
pling on the steering tube as shown in the figure.
Aesthetic inspection
Appearance check:
- Paintwork
- Fitting of plastics
- Scratches
- Dirt
Tightening torques inspection
Lock check
- Safety locks
- clamping screws
Safety locks
•
Rear shock absorber upper fixing
•
Rear shock absorber lower fixing
•
Front shock absorber upper fixing
•
Front shock absorber lower fixing
•
Sliding stems fixing
•
Break callipers fixing
•
Front wheels fixing screws
•
Front wheels axle nut
•
Rear wheel axle nut
•
Chassis - engine swinging arm fixing
•
Handlebar lock nut
•
Lower ring nut for side steering tubes
•
Upper ring nut for side steering tubes
Pre-delivery MP3 125
PRE DE - 2
