020329Y MityVac vacuum-operated pump
Fuel supply
Removing the carburettor
- To detach the carburettor from the engine, it is
necessary to move the air filter and remove the
throttle control transmission, the automatic starter
connection, the clamps anchoring the carburettor
to the filter housing and to the inlet manifold, the
air delivery pipe to the diaphragm, the heater, the
intake fitting and the TPS cable.
- Remove the heater
- Remove the protection, the bracket and the start-
er acting on the screw shown in the figure.
MP3 125 Engine
ENG - 65
