Frame central cover
Side fairings
Remove the rear screw under the rear cover.
Remove the screw on the fairing front part, pull the
fairing to release the hooks.
Follow the same procedure for both fairings.
Remove the five screws on the right side and the
five on the left side, indicated in the figure.
MP3 125 Chassis
CHAS - 9
